Professional Series 1080p WDR Fixed HDCVI Mini Dome

Brand logo
SKU VSCVI2MPVDIRV2
Brand logo

Professional Series 1080p WDR Fixed HDCVI Mini Dome

SKU VSCVI2MPVDIRV2

Making analogue upgrade installations easy. Upgrade from analogue with the VSCVI2MPVDIRV2 and enjoy up to 5 times the resolution of D1 analogue cameras.

Camera features:
• Stream up to 1080p/2.0MP (1920 x 1080) at 25fps
• Fixed 3.6mm lens with wide viewing angles
• Up to 700m video transmission over coaxial cable
• Smart infrared illumination, up to 30m range
• Dual BNC outputs for HD and composite video
• True WDR (120dB) and 2D/3D noise reduction
• IP67/IK10 for weather and vandal resistance
• Compact Ø110mm base & variety of accessories

Backwards compatible: HDCVI/Analogue dual BNC video outputs.
Analogue mode configuration via OSD using HDCVI DVR or tester.

Suggested Products

Suggested product image
Adapter for Ceiling & Wall Mount Brackets
VSBKTA106
Suggested product image
Adapter/Junction Box for Surveillance Cameras
VSBKTA123
Suggested product image
Adapter/Junction Box for Surveillance Cameras
VSBKTA136
Suggested product image
Corner Wall Mount Camera Bracket
VSBKTA151
Suggested product image
Dual Clamp Pole Mount Camera Bracket
VSBKTA152
Suggested product image
Rain Cover Dome Camera Bracket
VSBKTA200W
Suggested product image
Right Angle Wall Mount Camera Bracket
VSBKTB203W
Suggested product image
760mm Ceiling Mount Dome Bracket
VSBKTB220C
Suggested product image
Right Angle Wall Mount Dome Bracket
VSBKTB305W

Links and Downloads

Securview VDIR Pro Dome Datasheet (PDF) 0.85 MB
Securview Accessory Compatibility Guide - Apr 2018 (PDF) 0.81 MB
CE/ RCM Certificate
RoHS Certificate

Specifications

General
Image Sensor
1/2.7” 2.1 Megapixel CMOS
Max. Resolution
2.0 Megapixel
Effective Pixels
1928 (H) x 1088 (V)
Signal Noise Ratio
> 50dB
Camera
Lens
3.6mm F1.2 Fixed Lens
Lens Type
Fixed
Angle of View
90°
Focus
Fixed / 0.8m Min. Focus Distance
Minimum Illumination
0.05 Lux at F1.2 (Colour) / 0 Lux IR Active
Electronic Shutter
1/3 ~ 1/100,000s
Day/Night
Auto (ICR) / Colour / B&W
Infrared Range
30m
White Balance
Auto / Manual
Noise Reduction
2D / 3D
Gain Control
Auto
Lighting Compensation
BLC / HLC / WDR (120dB)
DORI Distance (Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)
Detect (25px/m)
Observe (63px/m)
Recognise (125px/m)
Identify (250px/m)
Video
Resolution
1080p (1920 x 1080) to CIF (352 x 288)
Frame Rate
25fps (1080p and lower)
Transmission Distance
Rated for up to 700m via 75-3 coaxial cable (performed in ideal test conditions)
Interface
Audio Input
N/A
Alarm Interface
N/A
Video Output
2 x BNC video output (1 x HDCVI / 1 x Composite SD)
Modes Supported
Mode Switching
Synchronisation
Internal
OSD Menu
Support
Environmental
Ingress Protection
IP67
Vandal Resistant
IK10
Series
Housing
Metal, Polycarbonate
Camera Type
Dome
Tri-Axis Mounting
Yes
Power Input
12VDC
Power Consumption
< 4.5W
Dimensions
Ø110 x 81mm
Weight
0.30kg
Operating Environment
-30° to 60°C / RH95% (max)
Other
Analogue Support
Yes (Dual output)
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
113 mm
Height
139 mm
Depth
135 mm
Weight
0.56 kg
