3/24VDC Relay Module (Two 7A SPDT Relays)

SKU RLM7A-SDL

3/24VDC Relay Module (Two 7A SPDT Relays)

SKU RLM7A-SDL

Stock may be limited. Please contact us for availability or for an alternative item.

Expand your wiring and installation options with the useful Watchguard™ range of relay modules. Featuring heavy duty, low-current, high sensitivity and break-away modules, you’ll always have the perfect relay for the job.

Series features:
• Relay modules for any application where switches are required
• Pre-wired to easy-to-install modules
• Screw terminals allow easy installation without soldering or other time-consuming connections
• Wide-selection available: Choose single or dual relays, low-current or heavy-duty operation, and high-sensitivity or normal-sensitivity

Product features:
• 3~24VDC Low Trigger Voltage, perfect for keypads.
• Low Current Drain (60mA)
• High Sensitivity (1mA Trigger)
• Two 7A Form C SPDT Relays

Suggested Products

3/24VDC Relay Module (One 2A DPDT Relay)
RLM2A-DDL

6/12VDC Relay Module (One 5A DPDT Relay)
RLM5A-DD

12/24VDC 10-Pack Relay Module (One 7A SPDT Relay)
RLM7A-SD-10

Watchguard Professional 8 Zone Alarm Panel & LCD Keypad - Expandable to 64 Monitored Zones
WGAP864

High Quality LCD Keypad for WGAP864 Alarm System
WGAP864KP

Links and Downloads

Relay Module Series (PDF) 0.33 MB

CE/ RCM Certificate

RoHS Certificate

Specifications

Current Draw

60mA@12/24VDC

Dimensions

60 x 40 x 20 mm

No. of Relays

Operating Voltage

12/24 VDC

Relay Ratings

Relay Type

SPDT

Trigger Voltage

3~24 VDC

Voltage Selection

Jumper

Weight

55g

Warranty (Years)

TBA

Shipping Weight and Dimensions

Includes product packaging

Width

88 mm

Height

83 mm

Depth

48 mm

Weight

0.06 kg
