4-Port HDMI Splitter

SKU HDMISPLIT4

4-Port HDMI Splitter

SKU HDMISPLIT4

Available by special order only. Please contact us for lead times.

The HDMISPLIT4 is a high performance HDMI distribution amplifier. It allows one HDMI source to connect up to 4 HDMI displays simultaneously.

Features:
• Solid and durable metal housing with all connectors lined up in one side
• Built-in HDCP keysets allows each output to work independently when connecting to a HDMI display
• Splits a HDMI source up to 4 outputs at 1080p without signal loss
• Supports DVI source and DVI display by using HDMI to/from DVI adaptor cable
• Supports a wide range of PC and HDTV resolutions, from VGA to UXGA and 480p to 1080p
• Maximum resolution bandwidth supports 165 MHz
• Can be cascaded for more outputs
• Each of the buffered output can run up to 15 meters@1600x1200 or 1080p
• Support multi-channel compressed and uncompressed HDMI audio
• Full HDCP compliant
• Enhance function for signal pre-emphasis
• Fast handshaking reduces pre-picture blackout time to 5 seconds

Links and Downloads

HDMISPLIT4 User Manual (PDF) 0.66 MB

CE/ RCM Certificate

RoHS Certificate

Specifications

Warranty (Years)

Shipping Weight and Dimensions

Includes product packaging

Width

190 mm

Height

290 mm

Depth

70 mm

Weight

1.00 kg
