Ubiquiti Dual Band WiFi 6 (PoE) Access Point

Brand logo
SKU WT5-U6P
Brand logo

Ubiquiti Dual Band WiFi 6 (PoE) Access Point

SKU WT5-U6P

The WT5-U6P, Ubiquiti U6+ is a compact, high speed access point, delivering dual band WiFi 6 up to 115m² .

The WT5-U6P is an ideal access point for residential and small to medium sized commercial applications.

• 802.11a/b/g, WiFi 4/5/6 supported WiFi standards
• 2x2 MIMO 2.4GHz and 2x2 MIMO 5GHz 23dBm antennas
• High throughput rates up to 573Mbps (2.4GHz) and 2402Mbps (5GHz)
• Supports over 300 connected devices; concurrent clients
• Gigabit Ethernet (1000M) RJ45 uplink/networking interface
• PoE powered; 44~57V DC supported voltage (PoE switch or injector sold separately)
• UniFi 7.3 and later for management and AP configuration (QoS, VLAN)
• Polycarbonate and aluminium construction; ABS & steel mount plate
• Overall dimensions Ø160mm x 33mm, 413g total weight
• For indoor use only

Suggested Products

Suggested product image
UniFi PoE Device Adapter
POE-AF
Suggested product image
30W Power Over Ethernet Injector
VSPOE-IN30
Suggested product image
8-port Unmanaged Gigabit Hi-PoE Ethernet Switch
VSPOE-SWB8G

Links and Downloads

WT5-U6P - Product Specifications
WT5-U6P - Installation Guides
CE/ RCM Certificate
RoHS Certificate

Specifications

General
Dimensions
Ø160mm x 33mm
Weight
338g, 413g with mount
Enclosure
Polycarbonate & Aluminium Enclosure, ABS and Steel Mount Plate
LED Indicators
White/Blue LED
Buttons
Factory Reset Button
Mounting Components
Wall, Ceiling Mount (included)
Weather Resistance
Indoor Only
Operating Temperature
-30 ~ 60°C
Operating Humidity
5 ~ 95% (non-condensing)
Certifications
CE, FCC, IC
Interface
Network
1 x GbE RJ45 port
Management
Ethernet
Power
Power Method
PoE
Power Supply
N/A
Supported Voltage Range
44 ~ 57VDC
Max. Power Consumption
9W
Performance
Max. Coverage
115m²
Max. Transmission Power
23dBm (2.4GHz, 5GHz)
MIMO Configuration
2 x 2 (2.4GHz, 5GHz)
Throughput Rate
573Mbps (2.4GHz), 2402Mbps (5GHz)
Antenna Gain
3dBi (2.4GHz), 5.4dBi (5GHz)
Software
WiFi Standards
802.11a/b/g/n/ac/ax
Wireless Security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID
8 per Radio
VLAN
802.1Q
Advanced QoS
Per-user Rate Limiting
Guest Traffic Isolation
Supported
Zero-wait DFS
Supported* (firmware dependent)
Concurrent Clients
300+
Management Application
UniFi Network Version 6.0.34 and later
Warranty (Years)
1

Shipping Weight and Dimensions

Includes product packaging

Width
120 mm
Height
190 mm
Depth
70 mm
Weight
1.00 kg
