VSVIDEOWALL: Expandable Video Wall Controller

The VSVIDEOWALL expandable 19’’ rackmount video wall controller supports large scale encoding and decoding operations as well as video wall control via VIP Vision™ video management software.

Product Features:
- 19’’ 4U rackmount expandable video wall controller
- Flexible configuration with simple plug-in card module design
- Features 10 service card slots for video input/video output cards
- Video wall splicing configurations up to a maximum of 40 displays
- Manage video wall configuration via VIP Vision™ Smart PSS/DSS
- Encoding: Up to 80 channels at 1080p or 320 channels at D1
- Decoding: Up to 160 channels at 1080p or 640 channels at D1
- Supports TCP/IP / RTP / RTSP / RTCP / TCP / UDP / DHCP / PPPoE
- Supports switching between SD and HD streams
- 2 x 10/100/1000M RJ45 gigabit network ports

Compatible Accessories: VSVWD-H (HDMI video decoding card)
- Features 4 x HDMI input card module (also available in DVI-I, VGA optional)
- Decode 16 channels at 1080p / 32 channels at 720p / 64 channels at D1

Video wall controller range is available by special order only
Video encoding, video decoding and SAS storage expanders optional
Please contact your sales representative for more information
