Touch Screen Camera & Cable Tester

Brand logo
SKU VSTEST110
Brand logo

Touch Screen Camera & Cable Tester

SKU VSTEST110

Stock may be limited. Please contact us for availability or for an alternative item.

The VSTEST110 allows you to test IP or analogue cameras via touch screen, as well as a range of cables, with camera live-view, PTZ control, recording and audio testing, network testing/configuration and much more.

Product features:
• 7.0" IPS touch screen display (1920 x 1200) + 14 control keys
• Test real time video, PTZ control, audio test, live view & record
• 3 x RJ45 (100M), 3 x BNC (2 x in, 1 x out), RS485, USB, IP Surveillance (ONVIF protocol)
• Digital multi-meter, testing current, voltage and more
• HDMI input/output and audio input/output
• Configure: static IP, DHCP client, DHCP server, camera configuration
• Test: Real-time video, PTZ control, audio test, view and record
• H.265 decoding for cameras up to 8.0MP
• Over 30 protocols for PTZ control with up to 115200bps baud rate
• Generate PAL/NTSC video signals; support for local footage playback
• Network, coax and optical cable testing
• Up to 10 hours operation time with 5~6 hours recharge time
• LED flashlight with support for firmware upgrades via SD or online

Suggested Products

Suggested product image
UTC Video Output Controller
VSSELECT101
Suggested product image
Surveillance Camera & Cable Tester
VSTEST101

Links and Downloads

VSTEST Series Datasheet (PDF) 0.62 MB
VSTEST110 User Manual (PDF) 25.33 MB
CE/ RCM Certificate
RoHS Certificate

Specifications

Physical
Network Port
3 x 10/100 RJ45 port, support switch mode
BNC Port
2 x Video In (SDI, HDCVI/TVI/AHD/Composite), 1 x Video Out
Function Port
1 x TDR, 1 x OPM, 1 x VLS, 1 x RS485, 1 x HDMI In, 1 x HDMI Out, 1 x Audio In, 1 x Audio Out, 1 x microSD
Screen
7.0'' capacitive touch screen, 16.7M colour, 323 PPI 1920 x 1200 resolution (16:10 aspect ratio)
Operation Method
Touch screen, Power key, 14 control keys
Auto Power Off
Disable / 1~30 minutes
Tools
Data Monitor (from RS485 device) / Audio Recorder / Flashlight (Toggle with LED On/Off Button) / Notepad / Calculator
Updates
Support online updates and local updates via SD card
PoE
PD Test
Tester as a powered device (using 802.3at) / Detects power supply voltage
PSE Test
Tester as a power source, up to 25.5w (802.3at) / Detects powered device actual power
IP Camera Testing
IP Camera Protocol
ONVIF
Ethernet Test
10/100M Ethernet link test, loop detect, Ethernet traffic flow monitor, IP adress scan, ping test, DCHP server
IP Camera Resolution
Up to 8.0MP
IP Configuration
Static IP/ DHCP client/ DHCP server
IP Camera Test
Discover camera, real time video, camera configuration, PTZ control, audio test, full screen preview and digital zoom, snapshot, record video (recording original data stream)
IP Camera Digital Zoom
5 x Digital zoom
Coaxial Camera Testing
Video Formats
HDCVI / AHD / TVI / Composite
Video Encoding
PAL, NTSC (auto-detect) / H.265, H.264
Resolution
HDCVI (up to 4.0MP) / AHD (up to 4.0MP) TVI (up to 3.0MP)
Camera Test
Real time video / PTZ control / RS485 control / Audio test/ Full screen preview with digital zoom / Snapshot / Record video / Video play back
Coaxial Camera Digital Zoom
5 x digital zoom
Coaxial OSD
Camera configuration
WiFi Test
WiFi Test
Support 2.4G WiFi frequency band, max. speed 150, allows it to receive a wireless network and view IP cameras
Signal Monitoring
N/A
Antenna Type
N/A
Optical
Calibration Wavelength
850 / 1300 / 1310 / 1490 / 1550 / 1625nm
Signal Strength
70 ~ +10 dBm
Connector
Interchangeable FC/PC
HDMI
HDMI In
Supports 1440 x 900p to 720 x 420p
HDMI Out
Supports 1920 x 1080p
PTZ
PTZ Protocol
More than 30 controls
Baud Rate
600 ~ 115200bps
Cable
Network Cable Testing
TDR method
Coaxial Cable Testing
TDR, Analog video generator
Optical Cable Testing
VFL (Visual fault locator)
Digital Multi-Meter
Metering Function
AC/DC voltage/ AC/DC current / resistance / capacitance / data hold / relative measurement / continuity testing
Power
Battery
1 x 7.4V li-ion polymer battery, 5000mAh, 37Wh
Power Output
12VDC 2A / USB: 5VDC 2A / PoE: 25.5w (803.2at)
Charging Time
5 ~ 6 hours
Time
8 ~ 10 hours
Environment
On-Board Storage
Built-in 8GB flash, SD card (max. 32GB)
Working Temperature
-10°C ~ +55°C
Working Humidity
30% ~ 90%
Dimensions
270 x 160 x 46mm
Weight
2.1kg
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
313 mm
Height
96 mm
Depth
286 mm
Weight
2.10 kg
