VSTEST100: Surveillance Camera & Cable Tester

• Test and configure IP, HDCVI and analogue surveillance cameras
• 4.0’’ IPS display (800 x 480), 12 control keys & flip-out QWERTY keyboard
• 2 x RJ45 (1000M), 2 x BNC (video in/out), RS485, USB and Audio-in IP Surveillance (ONVIF 2.4.1, RTSP, RTP protocols)
• Configure: static IP, DHCP client, DHCP server, camera configuration
• Test: camera discovery, realtime video PTZ control, audio, view and record HDCVI & Analogue Surveillance (PAL/NTSC, D1/720p/1080p)
• Configure: camera configuration (HDCVI); signal rate: 1Vpp
• Test: real time video, PTZ control, audio test, view and record
• Over 30 protocols for PTZ control with up to 19200bps baud rate
• TDR detection up to 150m; PoE testing (PD/PSE); and network analysis
• Generate PAL/NTSC video signals; support for local footage playback
• Power by PoE midspan; PoE (802.3af/at) and 12VDC/2A power outputs
• Up to 10 hours operation time with 3~4 hours recharge time
• Dual LED flashlight with support for online firmware upgrades
