Panorama Series 8.0MP 180° Panorama Dome

Brand logo
SKU VSIP8MPPAD
Brand logo

Panorama Series 8.0MP 180° Panorama Dome

SKU VSIP8MPPAD

Designed to perform the duties of multiple cameras, the VSIP8MPPAD from VIP Vision is a dedicated panoramic IP camera with 180° panorama stitching. Transform your surveillance experience through its unique four lens panoramic view.

Camera features:
• Unique 4 x 1/2.8" 2.0MP Progressive Scan CMOS image sensor array
• 4096 x 1800 pixels maximum stitched resolution
• 4 x 2.8mm fixed lens, 180° horizontal / 80° vertical field of view
• Face detection, people counting, heat-map, e-PTZ and more
• 2 channel alarm input / 2 output, 1 channel audio input/output
• BLC / HLC / digital WDR, 3D digital noise reduction
• 6 x infrared LED array, 30m panoramic infrared distance
• Power via 24VAC or PoE+ (802.3at, Class 4)
• IK10 vandal / IP67 weather resistant housing
• MicroSD slot up to 128GB, ONVIF compliant

Displays as single camera channel with 180° panoramic view (no dewarp modes).

Bracket adapter included (VSBKTA111). This camera requires an additional ceiling/wall mount bracket to be mounted (sold separately).

Suggested Products

Suggested product image
Ceiling/Wall Mount Adapter for PTZ Cameras
VSBKTA111
Suggested product image
Adapter/Junction Box for PTZ Dome Cameras
VSBKTA120
Suggested product image
Adapter/Junction Box for PTZ Dome Cameras
VSBKTA140
Suggested product image
Triple Clamp Pole Mount Camera Bracket
VSBKTA150
Suggested product image
Corner Wall Mount Camera Bracket
VSBKTA151
Suggested product image
Ceiling Mount Camera Bracket
VSBKTB300C
Suggested product image
Parapet Mount PTZ Camera Bracket
VSBKTB303S
Suggested product image
PTZ Right Angle Wall Mount Camera Bracket
VSBKTB303W

Links and Downloads

VIP Vision PAD Series Datasheet (PDF) 0.55 MB
VIP Vision PAD Series Quick Install Guide (PDF) 0.96 MB
Network Camera Web 3.0 Operation Manual V2.0.5 8.46 MB
CE/ RCM Certificate
RoHS Certificate

Specifications

Camera
Image Sensor
4 x 1/2.8’’ 2.0MP Progressive Scan CMOS
Max. Resolution
2.0 Megapixel
Effective Pixels
4096 (H) x 1800 (V)
RAM / ROM
1024MB / 128MB
Ultra Low Light Colour
Yes
Min Illumination
Colour: 0.007 Lux (F2.0, 1/3s) / 0.05 Lux (F2.0, 1/30s), 0 Lux/F2.0 (B/W)
S/N Ratio
> 50dB
Infrared
Yes
Infrared System
6 x Infrared LED, 30m range, Auto/Manual on/off control
Lens
Lens Type
Fixed
Lens / Iris
2.8mm F2.0 Fixed Lens
Field of View
Horizontal: 180°, Vertical: 80°
Focus
Fixed
DORI Distance (Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)
Detect (25px/m)
53m
Observe (63px/m)
21m
Recognise (125px/m)
10m
Identify (250px/m)
5m
Video
Resolution
4096 x 1800 (approx. 7.4MP) to 1024 x 452 (approx. 0.5MP)
Frame Rate (Main)
4096 x 1800 (1~25fps)
Frame Rate (Sub)
1024 x 452 (1 ~ 25fps)
Frame Rate (Third)
1920 x 832 (1 ~ 25fps)
Video Compression
H.265+ / H.265 / H.264+ / H.264
Bit Rate
H.265: 9Kbps ~ 10Mbps / H.264: 24Kbps ~ 16Mbps
Bit Rate Control
Constant bit rate (CBR) / Variable bit rate (VBR)
Day/Night
Auto (ICR) / Color / B&W
Lighting Compensation
BLC / HLC / DWDR
Smart Scene Adaptive (SSA)
White Balance
Auto / Natural / Street Lamp / Outdoor / Manual
Gain Control
Auto / Manual
Noise Reduction
3D DNR
Picture Control
-
IVS
IVS
Yes
Intelligent Functions
Motion Detection (4 zones), Region of Interest (4 zones), Privacy Masking (4 zones), Smart Infrared, Tripwire, Intrusion, Object Abandoned/Missing, Face Detection, People Counting, Heat Map, E-PTZ
Network
Ethernet
RJ-45 (100/1000Base-T)
Protocol
HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP
Streaming Method
Unicast / Multicast
Max. User Access
10 Users / 20 Users
RTMP Support
No
Interface
Video Interface
1 Port (for adjustment only)
Audio Interface
1 Input, 1 Output / Compression: G.711a / G.711Mu / AAC / G.726
Alarm Interface
2 Inputs / 2 Output
RS485
N/A
Edge Storage
MicroSD Card (up to 128GB) / NAS / Local PC
Interoperability
ONVIF / PSIA / CGI
Environmental
Power Supply
24VAC / PoE+ (802.3at)
Power Consumption
<25.5W
Operating Conditions
-40° ~ +60° C / Less than 95% RH
Ingress Protection
IP67
Weather Resistance
Yes
Vandal Resistance
IK10
Series
Panorama Series
Camera Type
Panorama
Housing
Metal
Pan/Tilt/Rotation
Pan: 0˚~355˚ ; Tilt: 0˚~75˚ ; Rotation: ±20˚
Tri-Axis Mounting
Yes
ePoE
No
Dimensions
Φ212mm x 169.5mm
Net Weight
3.60kg
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
250 mm
Height
200 mm
Depth
200 mm
Weight
4.60 kg
