Camera
Image Sensor
1/2.8" 2.0MP Starvis™ CMOS
Max. Resolution
2.0 Megapixel
Effective Pixels
1920 (H) x 1080 (V)
RAM / ROM
1024MB / 128MB
Ultra Low Light Colour
Yes
Min Illumination
0.005 Lux/F1.6 (Color), 0.0005 Lux/F1.6 (B/W)
S/N Ratio
> 55dB
Infrared
No
Infrared System
N/A
Lens
Lens Type
Motorised Varifocal
Lens / Iris
5.3 ~ 64mm F1.6 ~ F4.4 Motorised Lens
Field of View
Horizontal: 59° ~ 5° (12x Optical Zoom)
Focus
Auto/Manual / 1m Min. Focus Distance
DORI Distance (Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)
Detect (25px/m)
883m
Observe (63px/m)
353m
Recognise (125px/m)
177m
Identify (250px/m)
88m
PTZ
Pan / Tilt Range
Pan: 0° ~ 360° (endless) / Tilt: -2° ~ 90° / Auto-flip 180°
PTZ Speed
Preset: Pan: 300°/s; Tilt: 200°/s Manual: Pan: 300°/s; Tilt: 120°/s
Modes / Presets
Up to 300 presets / 5 Pattern, 8 Tour, Auto Pan, Auto Scan
Start-up Action
Auto-restore to previous PTZ/lens status
Auto Tracking
N/A
Video
Resolution
1080p (1920 x 1080) to CIF(352 x 288)
Frame Rate (Main)
1080p (1 ~ 25fps)
Frame Rate (Sub)
D1 (1 ~ 25fps)
Frame Rate (Third)
720p (1 ~ 25fps)
Video Compression
H.265 / H.264
Bit Rate
H.265/H.264: 448 ~ 8192Kbps
Bit Rate Control
Constant bit rate (CBR) / Variable bit rate (VBR)
Day/Night
Auto (ICR) / Color / B&W
Lighting Compensation
BLC / HLC / WDR (120dB)
White Balance
Auto / ATW / Indoor / Outdoor / Manual
Gain Control
Auto / Manual
Noise Reduction
Ultra 2D/3D DNR
Picture Control
Flip 180°
IVS
IVS
Yes
Intelligent Functions
Tripwire, Intrusion, Abandoned/Missing Object, Face Detection, Motion Detection, Region of Interest, Privacy Masking (24 zones), Defog
Network
Ethernet
RJ-45 (10Base-T/100Base-TX)
Protocol
IPv4/IPv6; HTTP; HTTPS; SSL; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP; RTSP; RTP; SMTP; NTP; DHCP; DNS; PPPOE; DDNS; FTP; IP Filter; QoS; Bonjour; 802.1x
Streaming Method
Unicast / Multicast
Max. User Access
10 Users / 20 Users
RTMP Support
No
Interface
Video Interface
N/A
Audio Interface
1 Input, 1 Output / Compression: G.711a, G.711mu, G.726, AAC
Alarm Interface
2 Inputs / 1 Output
RS485
N/A
Edge Storage
MicroSD Card (up to 256GB) / NAS / Local PC
Interoperability
ONVIF / PSIA / CGI
Environmental
Power Supply
24VAC/1.5A / PoE+ (802.3at)
Power Consumption
<12W
Operating Conditions
-30° ~ +60° C / Less than 90% RH
Ingress Protection
IP66
Weather Resistance
Yes
Vandal Resistance
IK10
Series
Professional Series
Camera Type
PTZ Dome
Housing
Metal
Pan/Tilt/Rotation
Pan: 0° ~360 ° ; Tilt: -2° ~ 90° ; Rotation: 0° ~ 360°
Tri-Axis Mounting
No
ePoE
No
Dimensions
Ø170mm x 155mm
Net Weight
1.8kg
Other
Category
Network Surveillance
Smart Scene Adaptive (SSA)
No
Warranty (Years)
4
