Professional Series 4.0MP WDR Fixed HDCVI Mini Bullet

Brand logo
SKU VSCVI4MPFBIR2.8
Brand logo

Professional Series 4.0MP WDR Fixed HDCVI Mini Bullet

SKU VSCVI4MPFBIR2.8

High performance fixed-lens surveillance in a compact body. The VSCVI4MPFBIR2.8 offers professional features to take your surveillance to the next level, including true WDR, dual video outputs and smart infrared.

Camera features:
• Stream up to 4.0MP (2560 x 1440) at 25fps
• Fixed 2.8mm lens with wide viewing angles
• Up to 700m video transmission over coaxial cable
• Smart infrared illumination, up to 40m range
• Dual BNC outputs for HD and composite video
• True WDR (120dB) and 2D/3D noise reduction
• IP67 rated weather resistant metal housing
• Compact bullet, ideal for under eaves, walls, etc.

Backwards compatible: Dual BNC video output for HDCVI or Analogue.
Analogue mode configuration via OSD using HDCVI DVR or tester.

Suggested Products

Suggested product image
Adapter/Junction Box for Surveillance Cameras
VSBKTA121
Suggested product image
Adapter/Junction Box for Surveillance Cameras
VSBKTA130E
Suggested product image
Corner Wall Mount Camera Bracket
VSBKTA151
Suggested product image
Dual Clamp Pole Mount Camera Bracket
VSBKTA152
Suggested product image
Dual Clamp Pole Mount Camera Bracket
VSBKTA152E

Links and Downloads

Securview FBIR Series Datasheet (PDF) 0.75 MB
Securview Accessory Compatibility Guide - Apr 2018 (PDF) 0.81 MB
CE/ RCM Certificate
RoHS Certificate

Specifications

General
Image Sensor
1/3” 4.1 Megapixel CMOS
Max. Resolution
4.0 Megapixel
Effective Pixels
1/4 ~ 1/100,000s
Signal Noise Ratio
> 65dB
Camera
Lens
2.8mm F1.5 Fixed Lens
Lens Type
Fixed
Angle of View
99.7°
Focus
Fixed / 1.5m Min. Focus Distance
Minimum Illumination
0.01 Lux at F1.5 (Colour) / 0 Lux IR Active
Electronic Shutter
1/3 ~ 1/300,000s
Day/Night
Auto (ICR) / Manual
Infrared Range
40m
White Balance
Auto / Manual
Noise Reduction
2D / 3D
Gain Control
Auto
Lighting Compensation
BLC / HLC / WDR (120dB)
DORI Distance (Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)
Detect (25px/m)
80m
Observe (63px/m)
32m
Recognise (125px/m)
16m
Identify (250px/m)
8m
Video
Resolution
4.0MP (2560 x 1440) to CIF (352 x 288)
Frame Rate
25fps (4.0MP), 25fps (1080p and lower)
Transmission Distance
Rated for up to 700m via 75-3 coaxial cable (performed in ideal test conditions)
Interface
Audio Input
N/A
Alarm Interface
N/A
Video Output
2 x BNC video output (1 x HDCVI / 1 x Composite SD)
Modes Supported
Mode Switching
Synchronisation
Internal
OSD Menu
Support
Environmental
Ingress Protection
IP67
Vandal Resistant
N/A
Series
Housing
Metal
Camera Type
Bullet
Tri-Axis Mounting
No
Power Input
12VDC
Power Consumption
< 5.9W
Dimensions
180 x 70 x 70mm
Weight
0.40kg
Operating Environment
-30° to 60°C / RH95% (max)
Other
Analogue Support
Yes (Dual output)
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
100 mm
Height
100 mm
Depth
180 mm
Weight
0.53 kg
