Compact Series 1080p Fixed HDCVI Mini Turret

Brand logo
SKU VSCVI2MPDIRV5
Brand logo

Compact Series 1080p Fixed HDCVI Mini Turret

SKU VSCVI2MPDIRV5

Stock may be limited. Please contact us for availability or for an alternative item.

Stream in real-time at 1080p Full HD with the VSCVI2MPDIRV5 Compact Series Fixed Mini Dome. Built with weather resistant housing, built in microphone, excellent low light performance, and long range infrared.

Camera Features:
• Streams HD 1080p/2.0MP (1920 x 1080)
• Fixed 3.6mm lens; 87° viewing angle
• Up to 800m HD video transmission over coax
• Superb low light performance (0.005lux @F1.6)
• Built-in microphone to record audio surveillance
• Infrared illumination up to 50m
• IP67 rated for weather resistance
• Compact size with adjustable mount
• Supports HDCVI, AHD, HDTVI & Composite video format modes
• Switch modes via OSD (menu on HDCVI recorder) or with the VSSELECT101 (UTC connector)

Suggested Products

Suggested product image
Adapter for Ceiling & Wall Mount Brackets
VSBKTA106
Suggested product image
780mm Extender for Ceiling Mount Bracket
VSBKTA117
Suggested product image
Adapter/Junction Box for Surveillance Cameras
VSBKTA130E
Suggested product image
Adapter/Junction Box for Surveillance Cameras
VSBKTA139
Suggested product image
Triple Clamp Pole Mount Camera Bracket
VSBKTA150
Suggested product image
Corner Wall Mount Camera Bracket
VSBKTA151
Suggested product image
Dual Clamp Pole Mount Camera Bracket
VSBKTA152E
Suggested product image
Right Angle Wall Mount Camera Bracket
VSBKTB204W
Suggested product image
760mm Ceiling Mount Dome Bracket
VSBKTB220C
Suggested product image
Right Angle Wall Mount Dome Bracket
VSBKTB305W
Suggested product image
UTC Video Output Controller
VSSELECT101

Links and Downloads

Watchguard DIR Compact Turret Dome Datasheet (PDF) 0.47 MB
Accessory Compatibility Guide - Q1 2021 (PDF) 1.75 MB
CE/ RCM Certificate
RoHS Certificate

Specifications

General
Image Sensor
1/2.8” 2.0 Megapixel CMOS
Max. Resolution
2.0 Megapixel
Effective Pixels
1920 (H) x 1080 (V)
Signal Noise Ratio
> 65dB
Camera
Lens
3.6mm Fixed Lens
Lens Type
Fixed
Angle of View
87°
Focus
Fixed
Minimum Illumination
0.005 Lux at F1.6 (Colour) / 30IRE, 0 Lux IR Active
Electronic Shutter
1/4 ~ 1/100,000s
Day/Night
Auto (ICR) / Colour / B&W
Infrared Range
50m
White Balance
Auto / Manual
Noise Reduction
2D
Gain Control
AGC
Lighting Compensation
BLC / HLC / DWDR
DORI Distance (Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)
Detect (25px/m)
55m
Observe (63px/m)
22m
Recognise (125px/m)
11m
Identify (250px/m)
6m
Video
Resolution
1080p (1920 x 1080) to CIF (352 x 288)
Frame Rate
25fps (1080p and lower)
Transmission Distance
Over 800m via 75-3 coaxial cable
Interface
Audio Input
Built-in Microphone
Alarm Interface
N/A
Video Output
1 x BNC SD / HD / TVI / AHD video output (switchable with VSSELECT101)
Modes Supported
HDCVI, AHD, HDTVI & Composite
Mode Switching
OSD (via HDCVI recorder) / VSSELECT101 (UTC connector)
Synchronisation
Internal
OSD Menu
Multi language
Environmental
Ingress Protection
IP67
Vandal Resistant
No
Series
Compact Series
Housing
Metal
Camera Type
Turret
Tri-Axis Mounting
Yes
Power Input
12VDC
Power Consumption
< 4.7W
Dimensions
Ø106 x 94mm
Weight
0.44kg
Operating Environment
-40° to 60°C / RH90% (max)
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
136 mm
Height
137 mm
Depth
113 mm
Weight
0.56 kg
