16 port 10/100 Power over Ethernet Unmanaged Switch

Brand logo
SKU VS16PORTPOE
Brand logo

16 port 10/100 Power over Ethernet Unmanaged Switch

SKU VS16PORTPOE

Stock may be limited. Please contact us for availability or for an alternative item.

The VS16PORTPOE is a 16 port 10/100Mbps Power over Ethernet switch, with an additional 2 gigabit SFP ports The PoE switch features 16 x 10/100M PoE ethernet ports, making it perfect for quick installation of PoE devices such as IP cameras, wireless access points, and VoIP devices by transmitting both power and data through the same cable. It also features auto MDI/MDIX, with store-and-forward transmission modes.

The switch supplies a maximum of 250W of power. It can automatically detect your PoE devices and their power class, minimising the possibility of damaging your equipment with the wrong power supply. The VS16PORTPOE switch can support PoE devices installed up to 100m (CAT5 cable). This unmanaged, plug & play PoE switch makes network installations quick and easy, with no need for advanced configuration or setup.

Links and Downloads

CE/ RCM Certificate
RoHS Certificate

Specifications

Backplane Bandwith
7.2Gbps
Buffer Memory
96KB embedded memory per unit
Dimensions
440 x 330 x 44mm
Housing Construction
Iron
LED Indicator
System: Power, PoE max. power / Per Port: Link, activity, speed, PoE active, PoE fault
MAC Address Database
1,000 media access control addresses per system
MAC Address List
48-bit
Network Ports
1~16 PoE ethernet ports: 10/100Mbps / 2 Uplink ethernet Ports: 10/100Mbps
Network Protocol Standard
IEEE802.3i: 10BASE-T / IEEE802.3u: 100BASE-TX / IEEE802.3x: Flow Control / IEEE802.3af: Power over Ethernet / IEEE802.3at: Power over Ethernet
Operating Environment
0° ~ 55°C
Packet Forwarding Rate
1.49Mbps
PoE Power Supply Parameter
IEEE802.3af: 15.4W per port / IEEE802.3at: 30W per port
Power Consumption
250W
Transmission Distance
100m
Transmission Medium
CAT5 / CAT5E / CAT6 standard network cable
Transmission Mode
Full-duplex/Half-duplex (adaptive)
Weight
1.3kg
Warranty (Years)
1
