2-Piece Ethernet RJ45 Connector

SKU RJ45CJCAT62

2-Piece Ethernet RJ45 Connector

SKU RJ45CJCAT62

This product is Coming Soon. Please contact us for more information.

The RJ45CJCAT62 Ethernet Connector is engineered to provide consistent, high-performance networking solutions. Designed for compatibility with Cat5, Cat5e, and Cat6 cables, it delivers reliable, fast and secure connections for residential and commercial applications. Built to industry standards, this connector ensures durability and optimal functionality in various networking scenarios.

Key Features:
• Rj45 modular plug, optimised for Ethernet networking applications.
• Fully compatible with Cat5, Cat5e, and Cat6 cables, supporting both solid and stranded wire configurations.
• Capable of supporting speeds up to 1Gbps, ensuring efficient and uninterrupted data transfer.
• Gold-plated 8P8C pins for enhanced conductivity, corrosion resistance, and long-term performance.

Links and Downloads

CE/ RCM Certificate

RoHS Certificate

Specifications

Bandwidth

Supports frequencies up to 500 MHz (Ideal for high-speed data transfer and networking)

Cable Compatibility

Cat5, Cat5e, Cat6, and Cat6a (works with both solid and stranded cables)

Connector Dimensions

21mm x 9mm x 10mm (L x W x H)

Connector Type

Gold-plated copper contacts for corrosion resistance and improved signal intergrity

Crimping Tool Compatibility

Compatible with standard RJ45 crimping tools for accurate and easy installation

Data Rate Support

Supports up to 10Gbps Ethernet speeds (Ideal for Gigabit and 10Gbps networks)

Dielectric Strength

Rated for 1000V AC for 60 seconds (Ensures safe, reliable operation in networking environments)

Durability

Rated for up to 750 plug-in/plug-out cycles without performance degradation

Electrical Performance

Contact resistance: <20mΩ

Housing Material

Clear polycarbonate or ABS plastic housing for impact resistance and wire alignment visability

Insulation Resistance

>500MΩ at 500v DC

Latch Design

Features a snag-free latch design to prevent breakage during installation and handling

Operating Temperature Range

-40°C to 85°C (Suitable for indoor and outdoor installations)

Pin Configuration

Precision 8 gold-plated pins for stable and reliable signal transmission

Product Type

RJ45 Modular Plug Ethernet Cable Connector

RoHS Compliance

Free from hazardous substances, enduring environmental safety

Sheilding

Unsheilded (UTP) - Ideal for standard Ethernet networking applications

Storage Temperature Range

-40°C to 100°C

Wire Gauge Compatibility

Compatible with 23 AWG to 26 AWG wire (Standard and stranded wire)

Wire Insertion Guide

Includes staggered alignment grooves for proper wire placement and easy termination

Warranty (Years)

Shipping Weight and Dimensions

Includes product packaging

Width

0 mm

Height

0 mm

Depth

0 mm

Weight

1.00 kg
