Professional 24 Channel Network Video Recorder with PoE (320Mbps)

Brand logo
SKU NVR24PRO6
Brand logo

Professional 24 Channel Network Video Recorder with PoE (320Mbps)

SKU NVR24PRO6

Stock may be limited. Please contact us for availability or for an alternative item.

The VIP Vision NVR24PRO6 is a 24 channel network video recorder, designed as an immediate and customisable high definition IP surveillance solution. This NVR offers native Ultra HD broadcast-quality image performance and easy installation with built in Power over Ethernet ports.

Product features:
• Record beyond Ultra HD up to 12.0MP (4000 x 3000)
• 24CH NVR with 24 Power over Ethernet ports
• Up to 320Mbps incoming bandwidth; H.265 support
• 4 x SATA ports up to 10TB, max. 40TB HDD capacity
• Remote view in seconds with setup via QR code
• Native Ultra HD live view on 4K monitors via HDMI
• Backup footage via network, USB or SATA devices
• Live view, playback & record via your phone/tablet

Suggested Products

Suggested product image
CAT5E Solid Core Cable Unshielded (Blue) 305m Pullbox
CAT5EBLU
Suggested product image
HDMI to VGA Adapter Cable
HDMITOVGA
Suggested product image
24" LG 1920 x 1080 LCD Monitor (IPS)
LCDLG24I
Suggested product image
6RU 600mm Wall-Mount Data Cabinet
RMC-B6U600W
Suggested product image
1000VA Smart Online UPS - 900W
UPS-B1000-O
Suggested product image
24-port Managed Fast Hi-PoE Ethernet Switch
VSPOE-SWA24

Links and Downloads

VIP Vision NVRPRO Series Datasheet (PDF) 0.76 MB
VIP Vision / Watchguard NVR Installation Manual - Q4 2021 (PDF) 3.63 MB
Product Feature Guide - VIP Vision ePoE Overview (PDF) 1.76 MB
Smart PSS V2.0.1 (Windows) 88.17 MB
Smart PSS V2.0 (Mac) 90.05 MB
Full NVR User Manual V4.3.0 - Blue GUI (PDF) 12.75 MB
Full NVR User Manual V4.5.1 - Black GUI (PDF) 14.69 MB
VIP Vision / Watchguard Mobile App Quick Start Guide (PDF) 2.57 MB
NVR Firmware Type F 2017-Current
CE/ RCM Certificate
RoHS Certificate

Specifications

General
Main Processor
Quad-core embedded processor
Operating System
Embedded Linux
Video Input
24 channels
PoE
Yes
HDD Capacity
Two-way Talk
1 channel input, 1 channel output, RCA
Interoperability
ONVIF 2.4, CGI conformant
Display
Video Output
2 x HDMI, 1 x VGA
Display Resolution
Configurable from 3840 x 2160 to 1024 x 768
Display Split
1/4/8/9/16/25
OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Recording Resolution
Configurable from 12.0MP (4000 x 3000) to CIF (352 x 288)
Incoming Bandwidth
320Mbps
Decoding Capacity
Video Compression
H.265 / H.264 / MJPEG / MPEG4
Bit Rate
16kbps ~ 20Mbps per channel
Record Modes
Manual / Schedule (Regular [Continuous], Motion Detection, Alarm) / Stop
Record Interval
1~120 min (default: 60 min) / Pre-record: 1~30s / Post-record: 10~300s
Features
Alarm Input / Output
16 channels input / 6 channels relay output (N.O/N.C)
Trigger Events
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer, Screentips
Video Detection
Motion Detection, Motion Zones: 396 (22 x 18), Video Loss & Tampering
Playback Sync
1/4/9/16
Search Modes
Time/Date, Alarm, Motion Detection, Exact Search (to the second), Smart Search
Backup Modes
USB Device / Network / eSATA Device
Network
Ethernet
1 x RJ-45 port (10/100/1000Mbps)
Power over Ethernet
24 ports (IEEE802.3at/af)
Network Functions
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search, P2P
Optical Interface
N/A
Max. User Access
128 users
Remote View
iOS (iPhone, iPad) / Android devices
Storage
Internal HDD
4 x SATA ports up to 10TB, max. 40TB HDD capacity
HDD Modes
Single (no RAID compatibility)
USB Interface
3 ports: Rear USB3.0 / Front USB2.0
Auxiliary Inputs
1 x RS232 / 1 x RS485 / 1 x eSATA
Environment
Power Supply
100 ~ 240VAC, 50 ~ 60Hz
Power Consumption
< 17.5W (without HDD) / PoE: 25.5W per port, 210W total
Operating Environment
-10 ~ 55°C / 10 ~ 90%RH / 86 ~ 106kpa
Rackmountable
Yes (included)
Rackmount Units
1.5RU
Dimensions
440 x 411 x 76mm
Weight
4.65kg (without HDD)
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
530 mm
Height
500 mm
Depth
220 mm
Weight
7.10 kg
