Professional Series 32 Channel 1080p HDCVI Digital Video Recorder

Brand logo
SKU CVR32PRO3
Brand logo

Professional Series 32 Channel 1080p HDCVI Digital Video Recorder

SKU CVR32PRO3

Stock may be limited. Please contact us for availability or for an alternative item.

The CVR32PRO3 is a 32 channel HDCVI DVR capable of Full HD 1080p recording over coaxial cable. It features compatibility with HDCVI, HDTVI, AHD, Analogue and IP video inputs, making it perfect for both new and retrofit CCTV installations.

Product features:
• Records up to Full HD 1080p at 15fps (HDCVI, HDTVI, AHD) and 960H at 25fps (analogue)
• H.265 high efficiency video compression
• 8 x SATA ports up to 10TB, max. 80TB HDD capacity
• Support for HDCVI, HDTVI, AHD, Analogue and IP video inputs
• Substitute coax channels for IP channels up to 8.0MP resolution
• Up to 700m video transmission distance over coaxial cable
• HDMI (up to UHD/4K) & VGA simultaneous video output
• Remote view for iOS & Android devices
• Configure iOS/Android remote view in seconds via QR code
• Backup via external USB device, eSATA device or local network
• Quiet smart fan auto adjusts with CPU temperature

Suggested Products

Suggested product image
19.5" Acer LED Monitor
LCDACER20
Suggested product image
1500VA Line Interactive UPS - 900W
UPS-A1500-L
Suggested product image
HDCVI to HDCVI / HDMI / VGA / Composite Video Converter
VSCVIDECODER
Suggested product image
BNC Video Ground Loop Isolator
VSGLI

Links and Downloads

CVRPRO Series DVRs Datasheet (PDF) 0.98 MB
HDCVI DVR Installer Manual v4.0 (PDF) 18.25 MB
HDCVI DVR Quick Start Guide (PDF) 2.88 MB
CVR_Firmware_Type1D_20221124 47.05 MB
CE/ RCM Certificate
RoHS Certificate

Specifications

General
Main Processor
Embedded Processor
Operating System
Embedded Linux
Video Input
32 channel BNC
Audio In/Out
16 / 1
Two-way Talk
1 channel input / output BNC
Internal HDD
8 SATA Ports, up to 80TB total
USB Interface
4 ports: 2x USB2.0, 2x USB3.0
Auxiliary Inputs
1 x RS232 port (PC comm. & keyboard) / 1 x RS485 / 1 x RS422 port (PTZ control)
Power Supply
100 ~ 240VAC, 50/60 Hz
Power Consumption
<35W (without HDD)
Operating Environment
-10 ~55°C / 10~90%RH / 86~106kpa
Dimensions
440mm x 455mm x 95mm (2U)
Rackmountable
Yes (included)
Rackmount Unit
2RU
Weight
7.0kg (without HDD)
Cross Compatibility
Supported Video Inputs
HDCVI / HDTVI / AHD / Composite / IP
Coax Input Support
32 channels
IP Input Support
32 channels (32 substitute, 0 additional)
IP Input Max. Resolution
8.0MP
IP Input Max. Bandwidth
128Mbps
Display
Video Output
2 HDMI / 1 VGA / 1 TV (BNC)
Display Resolution
1920 x 1080 to 1024 x 768
Display Split
1 / 4 / 8 / 9 / 16 / 25 / 36
OSD
Camera title, time, video loss, camera lock, motion detection, recording
Recording
Maximum Resolution
1080p (1920 x 1080) / 720p (1280 x 720)
Frame Rate (Main)
1080p (1~15fps), 720p (1~25fps)
Frame Rate (Sub)
D1 (1 ~ 15fps)
Frame Rate (Third)
N/A
Video Compression
H.265+ / H.265 / H.264+ / H.264
Bit Rate
32Kbps ~ 6144Kbps Per Channel
Record Modes
Manual / Schedule (Regular, Continuous), Motion Detection, Alarm, Stop
Record Interval
1~60 min (default: 60 min) / Pre: 1~30s / Post: 10~300s
Features
Alarm Input / Output
16 channel input / 6 relay output
Trigger Events
Recording; PTZ; tour; push video notification; email notification; FTP upload; snapshot; internal buzzer; and screen tip overlay
Video Detection
MD zones: 396 (22 × 18) / Video loss / Camera blank
Playback Sync
1 / 4 / 9 / 16
Search Modes
Time/Date; Alarm, Motion detection; Exact search (to the second)
Intelligent Functions
Face Detection, Tripwire, Abandoned/Missing Object
Backup Modes
USB Device / eSATA Device / Internal SATA burner (optional) / Network
Network
Ethernet
2x RJ-45 port (10/100M/1000M)
Network Functions
HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P, IP Search
Max. User Access
128 users
Remote View
iOS (iPhone, iPad); Android devices
Warranty (Years)
4

Shipping Weight and Dimensions

Includes product packaging

Width
570 mm
Height
220 mm
Depth
570 mm
Weight
9.70 kg
